Cable Ties

Cable ties are an extremely versatile way to organize
and bundle wires and cables. They are easy to install, and can
be cut off for rework very easily. Cable ties have also been referred
to as lashing ties, wire ties, zip ties and wire tidies. There
are several types of wire ties available, depending on your application.
Nylon cable ties are the most common type. You'll see them in
home repair centers, electrician supply houses, etc. Others are
much less common, and you need to visit websites like buy
heat shrink .com to find them.
Nylon
6/6 Cable Ties are by far the most popular and widely used
wire ties in the world. They can be used in most applications
at a continuous use temperature of from -40°F up to 185°F.
Nylon cable ties meet UL 94V-2 flammability rating, and our black
ties are weather and UV resistant for extended sunlight exposure.
There are three grades of Nylon material used in cable ties. All
of the ties listed on this page fall under one of two categories:
General Purpose Nylon 6,6 for all colors except black, and UV
Stabilized Nylon 6/6 for Black. Heat
Stabilized Nylon cable ties are rated for continuous use up
to 257°F, and are available on our Specialty
Cable Ties page
Tefzel®
Cable ties (ETFE [ethylene-tetrafluoroethylene]), although
weaker than Nylon are also extremely versatile. Used in high temperature
applications, Tefzel is also highly resistant to concentrated
acids (such as hydrofluoric acid, which is used for etching glass,
and sulfuric acid). In addition, in high humidity environments,
Tefzel is virtually unaffected.
Adding even further to Tefzel's versatility is its
radiation resistance up to 100 megarads, its high temperature
stability (rated for continuous use up to 302°F, or 150°C),
its ultraviolet (UV) light resistance, and its UL 94V-0 flame
rating.
Halar®
Cable Ties (ECTFE [ethylene-chlorotrifluoroethylene]), has
properties similar to Tefzel.
The major difference (besides the price) is that Halar resin is
rated for use in plenum
spaces. This is due to its low smoke density when burned.
Its durability is similar to Nylon, and is has excellent impact
resistance at normal temperatures as well as at very low temperatures.
Halar has good tensile, flexural, and wear-related properties.
Halar is also very gamma resistant, and is rated
for temperatures from -50°C to 150°C. It is also UV resistant
and carries a UL 94V-0 flame rating. Basically, if you need good
resistance to almost any environment, but low smoke generation
(i.e. plenum) is not a concern, go with Tefzel
ties, otherwise if you require that all of your components
be suitable for plenum
(air-handling) spaces, go with Halar
ties.
Some interesting ways to use cable ties
- Mark your luggage - put a few Fluorescent pink
cable ties on your suitcase. You can identify your bag from across
the room.
- Wine glass identification - Having a dinner party,
and can't remember which wine glass yours? Of course, it's the
one with the purple
cable tie on it. Easily use a colored cable tie as a wine
glass identifier
Nylon
6,6 Cable Ties
-
RoHS Compliant
-
Material: Nylon 6.6 (Black is weather resistant
and UV Stabilized)
-
Material Flammability Rating UL94V-2
-
Colors Available: Black, Natural,
Brown, Red, Orange,
Yellow, Green,
Blue, Purple,
Gray, Fluorescent Green,
FL. Pink, FL Yellow,
FL Orange, FL Blue

Black |
Natural |
Brown |
Red |
Orange |
Yellow |
Green |
Dark Blue |
Purple |
Gray |
Light Blue |
Fluor Orange |
FL Yellow |
FL Pink |
FL Green |

Top
Our
most popular Cable Ties
Note - all of our Black ties are UV Stabilized
Nominal Size |
Loop Tensile |
Max bundle Diameter |
Colors |
Qty/bag |
Price/bag |
Select Options and
Add to Cart
|
4" |
18
LB |
0.9" |
All |
100 |
$1.50 |
|
1000 |
$12.50 |
7" |
50
LB
|
1.9" |
Black,
Natural |
100 |
$4.00 |
|
| 1000 |
$25.00 |
8" |
40
LB
|
2.2" |
All |
100 |
$3.50 |
|
1000 |
$22.00 |
14" |
50LB |
4.0" |
All |
100 |
$9.50 |
|
500 |
$26.00 |
|
18 LB |
0.9" |
Blue |
100 |
$22.75 |
|
|
50
LB |
2.0" |
Blue |
100 |
$83 |
|
|
50 LB |
1.8" |
Black,
Natural |
100 |
$6.25 |
|
|
50 LB |
2.0" |
Black,
Natural |
100 |
$8.25 |
|
Top
Light
Duty (Miniature) Nylon Cable Ties
18 pound Loop tensile strength (0.1" wide)
Note - all of our Black ties are UV Stabilized
Nominal Size |
Actual Length |
Max bundle Diameter |
Colors |
Qty/bag |
Price/bag |
|
4" |
4.0" |
0.9"
|
All |
100 |
$1.50 |
|
1000 |
$12.50 |
6" |
5.5" |
1.3" |
Black,
Natural |
100 |
$2.95 |
|
1000 |
$27.50 |
8" |
7.9" |
2.2" |
Black,
Natural |
100 |
$3.75 |
|
1000 |
$32.00 |
Top
Intermediate
Nylon Cable Ties
40 pound Loop tensile strength (0.14" wide)
Note - all of our Black ties are UV Stabilized
Nominal Size |
Actual Length |
Max bundle Diameter |
Colors |
Qty/bag |
Price/bag |
|
6" |
5.5 |
1.4 |
All |
100 |
$2.50 |
|
1000 |
$17.00 |
8" |
7.9 |
2.4 |
All |
100 |
$3.50 |
|
1000 |
$22 |
11" |
11.8 |
3.0 |
Black,
Natural |
100 |
$5.50 |
|
1000 |
$47.00 |
| 14" |
14.6 |
4.0 |
Black,
Natural |
100 |
$9.00 |
|
| 1000 |
$75.00 |
Top
Standard
Nylon Cable Ties
50 pound Loop Tensile Strength (0.19" wide)
Note - all of our Black ties are UV Stabilized
Nominal Size |
Actual Length |
Max bundle Diameter |
Colors |
Qty/bag |
Price/bag |
|
7" |
7.4 |
1.9 |
All |
100 |
$4.00 |
|
1000 |
$25.00 |
11" |
11.8 |
3.1 |
All |
100 |
$10.50 |
|
1000 |
$59.00 |
14" |
14.5 |
4.0 |
All |
100 |
$9.50 |
|
500 |
$26.00 |
| 17" |
16.9 |
4.5 |
Black, Natural,
Red, Green, Yellow, Orange |
100 |
$12.00 |
|
| 21" |
20.9 |
6.0 |
Black, Natural |
100 |
$16.00 |
|
| 25" |
25.0 |
7.0 |
Natural |
100 |
$18.00 |
|
| 36" |
36.0 |
11.0 |
Natural |
100 |
$21.00 |
|
Top
Heavy
Duty Nylon 6,6 Cable Ties
120 pound Loop Tensile Strength (0.3" wide)
Note - all of our Black ties are UV Stabilized
Nominal Size |
Actual Length |
Max bundle Diameter |
Colors |
Qty/bag |
Price/bag |
|
8" |
7.9 |
2.4 |
Black, Natural |
100 |
$8.50 |
|
11" |
11.8 |
3.0 |
Black, Natural |
100 |
$15.00 |
|
14" |
14.5 |
4.1 |
All |
100 |
$11 Black/Natural |
|
$18 Colors |
|
| 18" |
18.0 |
4.9 |
Black, Natural |
100 |
$18.50 |
|
Top
Extra
Heavy Duty Cable Ties
175 pound Loop Tensile Strength (0.35" wide)
Note - all of our Black ties are UV Stabilized
Nominal Size |
Actual Length |
Max bundle Diameter |
Colors |
Qty/bag |
Price/bag |
|
18" |
17.7 |
4.3 |
Black, Natural |
100 |
$16.50 |
|
24" |
24.0 |
7.2 |
Black, Natural |
50 |
$9.75 |
|
36" |
35.9 |
11.0 |
Black, Natural |
50 |
$12.50 |
|
| 48" |
48.0 |
15.0 |
Black, Natural,
Gray |
50 |
$18 |
|
| 60" |
60.0 |
20.0 |
Black, Natural |
50 |
$50.50 |
|
250 pound Loop Tensile Strength
(0.5" wide)
Note - all of our Black ties are UV Stabilized
Nominal Size |
Actual Length |
Max bundle Diameter |
Colors |
Qty/bag |
Price/bag |
|
22" |
22.2 |
6.0 |
Black |
100 |
$35.00 |
|
34" |
34.2 |
10.0 |
Natural |
50 |
$25.00 |
|
| 40" |
40.1 |
12.0 |
Black |
50 |
$45.00 |
|
Top
|
Cable
Tie Tool
Heavy duty metal installation tool for use
with 18 - 50 lb. ties. Automatic cut-off and adjustable tensioning
for dependable use in assembly applications.

Actual
color of tool subject to change
Cable
Tie Tool
Heavy duty metal installation tool for use
with 18 - 50 lb. ties. Automatic cut-off and adjustable tensioning
for dependable use in assembly applications.

Actual
color of tool subject to change
Cable
Tie Tool
Heavy duty metal installation tool for use
with 18 - 50 lb. ties. Automatic cut-off and adjustable tensioning
for dependable use in assembly applications.

Actual
color of tool subject to change
Cable
Tie Tool
Heavy duty metal installation tool for use
with 18 - 50 lb. ties. Automatic cut-off and adjustable tensioning
for dependable use in assembly applications.

Actual
color of tool subject to change
Cable
Tie Tool
Rugged metal construction makes this tool
ideal for use with our 120 - 250lb. ties. Cinch tie to desired bundle
and pull trigger to cut excess flush at cable tie head.

Actual
color of tool subject to change
Cable
Tie Tool
Rugged metal construction makes this tool
ideal for use with our 120 - 250lb. ties. Cinch tie to desired bundle
and pull trigger to cut excess flush at cable tie head.

Actual
color of tool subject to change
|
